Inside or out, this exceptional all glass sliding door system makes a statement and is available in a frameless or framed design. Indoors it is the perfect room divider and outdoors it offers multiple uses and protection from the elements.
The SF20 single glazed slider offers complete versatility in design, with a two, three, four or five track slide and guide rail. The panels slide horizontally to one or two sides. On opening and closing, the first sliding panel and other panels are automatically opened and closed.
The SF20 can be designed to incorporate narrow frames and mid-rails to match the look of traditional steel doors. Perfect for dividing up open-plan living spaces the system combines the much sought-after Art Deco inspired design with modern performance and effortless usability.
Each panel, when closed, overlaps the adjacent panels by 23mm, providing permanent ventilation and protection from the elements. Increased rain and wind resistance can be achieved as an option, by clamping vertical profiles on to the glass with brush piles. The floor track with anti-slip coating, a flush track option is available so it can be recessed into the floor to provide a virtually unobstructed living space.
A bottom-running system ensures effortless movement of the sliding panels. The ball bearing-running mechanism is concealed within the bottom rail, limiting exposure to dirt and debris and providing quiet operation. The ceiling track offers up to 20mm in tolerance, while the bottom rollers can be adjusted in height by up to 5mm to allow for any inconsistencies and to compensate for structural variations.
With the addition of narrow mid-rails and a slender outer frame the SF20 can be designed to replicate the appearance of traditional steel, Crittall style steel doors and internal glass partitions.
Depending on your specification of 8mm or 10mm, toughened safety glass manufactured to BS EN 12600 standard can be used. This can be tinted or obscured if required.
Designed primarily as an internal system, the SF20 as standard does not incorporate a lock. However, there is an option to add a locking mechanism to the lead panel both internally and externally if required.
With the quality of our products and high standards of installation, we confidently provide a full ten-year warranty* on our systems and workmanship, ensuring complete peace of mind. Plus, unlike some warranties, if you decide to sell your home the IDSystems' guarantee is fully transferable to the new owner.
*Exclusions apply, please contact us for full details of warranty policy.
As standard, we offer the choice of any RAL colour in a semi-gloss finish, DB703 textured, DB703 smooth or silver anodised. Other RAL colours (over 200 RAL colours) are available for a nominal charge. In addition, you can specify whether a matt, semi-gloss or full-gloss level paint finish is required. Various handle options are available depending on your preference.
